273
8
Updated core, fixed a problem I identified with the flow being too direct and thus not slowing the gasses down enough. Works in 1.355" ID tubes. Central bore is 10mm. Also added a gap near the front where the gasses can all mix together for those who dont want to drill out a dozen holes into the top of their can. It will still improve performance if you did, but the front chamber should assist with lowering the gas pressure still. Version 2 and 3 were not published as I didnt like the flow characteristics and they didnt improve on the design of V1.
LBRY Tags: 2a; ftn; oil catch can; suppressor core; 3d printed
417
19
Flow through monocore for 6.8" D-cell oil catch tubes v20 with included end cap
Been working on this pretty frequently, testing and tweaking. Abandoned the DNA inspired helix aspect of the design and went for smaller and more cha…
270
12
6.5mm Flow through monocore for 6.8" D-cell oil catch tubes v20 with included end cap
Been working on this pretty frequently, testing and tweaking since I finally got my F1 approved by the ATFE.
Someone asked for a 22lr/556 variant. …
96
5
Dcell 1.355 Baffle drilling Jig with .75 x 1.375 Slip-Fixed Bushing Option
Dcell Baffle drilling jig that uses a metal 3/4" slip-fixed drill bushing that can be purchased on McMaster-Carr
LBRY Tags: fosscad; 2a; baffles
64
7
Helix Core flow through monocore for D-cell oil catch tubes
34.407mm D x 127mm L. Made in Blender, so dont beg for the STEP files, they don't exist.
LBRY Tags: 2a; ftn; suppressor; silencer; 5.56mm
