.1 Update is up
-Mag release spring hole corrected, 1mm less deep
-New stipples added

CHAIRMANWON GLOCK V3

Files are not released under any liscense. Commercial use is not premitted without my express consent.

BTC donation address 3QE1kvedKH79Xr3wKZ7nT9hnt7h8LjKh3Q

website can be found at origamifaceshield.com chairmanwon.com or chairmanjuan.com

Consult print orientation PDF for best results

DO NOT USE ANY NOZZLE LARGER THAN .4mm. THERE WILL BE HOLES IN THE PRINT IF YOU DO

Printing Profile Notes

Support X/Y Distance: 1.3mm (stops Cura from supporting stipples)
Use tree supports instead of normal supports (if you are suffering from very long slice times switch back to normal supports, you will waste material compared to trees but the print will be fine)
Enable Z hop on retract

If you are using Prusa Slicer make sure you have Detect Thin Walls set to off

Nozzle: 0.4mm
Layer Height: 0.16mm
Temp: 215-230/60C
Infill: 100%
Walls: 8
Supports: On/full - use a close support interface gap. Your interface gap should not be larger than 0.15mm unless you know what you are doing with your setup.
Cooling: As low as you can get away with for your printer

All other settings can/should be left as default or whatever you know works best with your printing setup.
