CAD Files for the US Army's M18 Handgun.
These files are being offered for free in the public interest, without approval or association with the manufacturer.
These files were obtained lawfully from a publicly accessible website (otbinnovations.com) where they were made available without any access restrictions or terms of use.
There is significant public interest in these files due to ongoing litigation regarding the P320's design and safety. Public access to accurate technical information about this firearm serves an important informational purpose.
These files have been stripped of all trademarks and logos
There go, Can’t stop the signal
u/M18PuffcoPeak · 2023-03-31 02:34:37 UTC · score 2
The file that Fiesty crayfish on grab cad made. It's just a reverse engineered airsoft one. It's missing a shit ton of dimensions.
u/M18PuffcoPeak · 2023-02-27 02:23:37 UTC · score 26
Honestly, while these dimensions are nice. There's a grabcad model that I modified and you can buy a flat bending jig off of GB to press it. The original flats weren't heat treated but if you use 10 gauge 4130 sheet metal, you can heat treat it afterwards in a large enough 120v knife kiln and some…
