This upload is from developer Steven Kiley who took the time to reverse engineer the Semi Auto AKM for future engineers and developers across the firearms community he has done amazing work for the firearms community and for that we thank him. You can find his profile linked here.
https://grabcad.com/library/akm-semi-auto-rifle-1
By popular demand, I have decided to upload my AKM assembly, along with main sub-assemblies.
This is the complete model of my AKM rifle, based off of a Romanian sample. Due to the size and complexity, importing may generate bugs. If this occurs, download the sub-assemblies and assemble yourself. You will need the stock screws and barrel pin from this assembly to complete.
Enjoy!
NOTE: The models that comprise this entire rifle WILL NOT manufacture a working weapon. The dimensions were taken by hand on a physical example, and many surfaces were simplified to make an "accurate" looking model. This model is in compliance with GrabCad's terms of use.
https://grabcad.com/library/akm-semi-auto-rifle-1
By popular demand, I have decided to upload my AKM assembly, along with main sub-assemblies.
This is the complete model of my AKM rifle, based off of a Romanian sample. Due to the size and complexity, importing may generate bugs. If this occurs, download the sub-assemblies and assemble yourself. You will need the stock screws and barrel pin from this assembly to complete.
Enjoy!
NOTE: The models that comprise this entire rifle WILL NOT manufacture a working weapon. The dimensions were taken by hand on a physical example, and many surfaces were simplified to make an "accurate" looking model. This model is in compliance with GrabCad's terms of use.
