LIL DUDE (Mini M-LOK to 1913 Adapter)

h* // haymarket customs @HaymarketCustoms:e
Details
Released Indexed 4.3MiB Creative Commons Attribution 4.0 International Automatically verified

The M-LOK to Picatinny rail you didn't know you didn't need.

Why? Because I'm teaching myself FreeCAD and because I wanted to model something
useful, ubiquitous, and well-documented. I made this model from scratch using
the Parts workbench and the original MIL-STD-1913 technical specification.

printing

Print using a filament suitable for functional parts. I have had excellent results
with PA6-GF/CF and PET-GF/CF. The 3MF file is oriented correctly and with the
recommended settings, but in short: print solid and orient such that the rail is
parallel to the print bed.

milling

todo soon

hardware

  • 2x M5 Button Head Socket Screws
  • 2x M5 T-nuts

changelog

  • 6/7/26 add relief for t-nut locking in mlok recoil lugs
    • cleanup files and update png
  • 6/6/26 initial release
